Details
SPECIFICATIONS
Display System
4K SXRD panel, projection system
Display Device
Size of effective display area: 0.61" x 3
Number of pixels
24,883,200 (3840 x 2160 x 3) pixels
Projection lens
Focus: Manual
Zoom
Manual (Approx. x 1.6)
Lens shift
Manual V ± 71 , H ± 25
Throw ratio
1.38:1 to 2.21:1
Light source
Laser diode
Light output
2,000 lm
Dynamic contrast
∞:1
Display resolution
720 x 576/50p 720 x 480/60p
1280 x 720/50p 1280 x 720/60p
1920 x 1080/50i 1920 x 1080/60i
1920 x 1080/24p 1920 x 1080/50p
1920 x 1080/60p 1920 x 1080/120p
3840 x 2160/24p 3840 x 2160/25p
3840 x 2160/30p 3840 x 2160/50p
3840 x 2160/60p 4096 x 2160/24p
4096 x 2160/25p 4096 x 2160/30p
4096 x 2160/50p 4096 x 2160/60p
Input / Output
HDMI x 2 (HDCP2.3)
Trigger x 1: Mini jack, DC 12V Max. 100mA
RS-232C x 1: D-sub 9-pin (male)
LAN: RJ45, 10BASE-T/100BASE-TX
IR IN: Mini jack
3D Sync Out: No
USB x 1: Type A, DC 5V, Max. 500mA
Picture Processor
X1™ Ultimate for projector
Object-based HDR remaster
Yes
Dynamic HDR Enhancer
Yes
Object-based Super Resolution:
Yes
Dual database processing
Yes
Digital Contrast Optimizer
Yes
Digital Focus Optimizer:
Yes
Dynamic Contrast Control
Dynamic laser control
Motionflow
Yes
HDR Format
HDR10 / HLG
3D
No
Picture Position Memory
No
Input lag reduction
Yes (4K / 2K)
Acoustic Noise:
24dB
Power requirements
AC 100V to 240V, 50/60Hz
Power consumption
In Use: 295W
Standby: 0.3W (when 'Remote Start' is set ot off)
Networked Standby: 0.5W
Dimensions (without protrusions)
W 460 x H 200 x D 472 mm (W 18 1/8 x H 7 7/8 x D 18 19/32 in)
Weight
Approx. 13 kg / 28 lb
Supplied accessories
Remote Control (RM-PJ28)
Size AA (R6) manganese batteries (2)
AC Power Cord (1)
Lens Cap (1)
Setup Guide (1)
