Details
Highlights
- Versatile Commercial Audio Solution: The Crown Audio G135MAE60 135MA is a powerful 3 x 1 mixer-amplifier designed for commercial audio applications.
- High-Quality Sound: Delivering clear and balanced audio with exceptional fidelity, this amplifier enhances the listening experience for all types of environments.
- Multiple Inputs: Equipped with three inputs, it allows easy integration of microphones, line-level sources, and even background music sources for seamless operation.
- Priority Function: The mixer-amplifier features a priority function that automatically lowers the background music volume when paging or making announcements, ensuring important messages are heard clearly.
- Energy-Efficient: With its Energy Star certification and standby mode, it helps reduce power consumption and operational costs, making it an eco-friendly choice for your audio setup.
Overview
The Crown Audio G135MAE60 135MA 3 x1 Commercial Mixer-Amplifier is the perfect solution for commercial audio installations that require flexibility, reliability, and exceptional sound quality. This mixer-amplifier is designed to meet the demands of various applications, including restaurants, offices, retail spaces, and more. With its powerful performance and versatile features, it offers an outstanding audio experience for both background music and paging applications.
Specifications
| Frequency Response (at 1 watt from line out) | 50 Hz to 20 kHz +/-1 dB 19 Hz to 34 kHz - 3 dB |
| Signal to Noise Ratio (ref. to rated power, master volume at minimum) | Mic: > 58 dB Line: > 60 dB Telephone: > 60 dB Inputs 2 or 3: > 78 dB |
| THD+Noise | <0.5% at rated power at 1 kHz <0.1% at 5W at 1 kHz |
| Input Sensitivity (for full output at maximum gain) | Input 1: Mic 3mV, Line 800 mV Input 2: 400mV Input 3: 400mV |
| Input Impedance (nominal) | Mic: 2.2 kilohms Line: 10 kilohms RCA: 10 kilohms |
| Crosstalk | -82 dB at 1 kHz (Ch. 1 line input 0.8V, Ch. 1 volume at minimum, other channel volumes at maximum) |
| Line Output Level (nominal) | 1V into 10 kilohms |
| Phantom Power | 15 VDC |
| AC Line Voltages Available | Universal Power Supply. Line voltage tolerance +15%, -20% |
| Operating Temperature/Humidity | 0 degrees C to 40 degrees C at 95% relative humidity (non-condensing) |
| Storage Temperature | -20 degrees C to 85 degrees C |
| IEC Power Connector | 15A |
Experience the convenience and performance of the Crown Audio G135MAE60 135MA 3 x1 Commercial Mixer-Amplifier. Whether you need background music in a restaurant, paging in an office, or audio distribution in a public space, this versatile mixer-amplifier delivers exceptional sound quality and reliable performance. With its energy-efficient design, multiple inputs, priority function, and wide range of available AC line voltages, it's the ideal audio solution for a wide range of commercial applications.
