Details
Highlights
- Immersive Sound: The JBL Control 126WT delivers exceptional audio performance with its 6.5" LF and 1" HF drivers, ensuring clear and powerful sound reproduction.
- Wide Frequency Range: Experience rich and detailed sound from 38 Hz to 20 kHz (-10 dB), perfect for both music and speech.
- Flexible Power Options: Choose from multiple transformer taps, including 70V: 30W, 15W, 7.5W, and 3.7W, allowing you to tailor the speaker's output to suit various applications.
- Wide Coverage Angle: The speaker offers a 180°H x 160°V coverage angle, ensuring even sound distribution across a wide area.
- High Sensitivity: With 88 dB SPL sensitivity, the JBL Control 126WT efficiently converts power to sound, providing impressive volume levels with low power consumption.
- Easy Installation: Designed for in-wall installations, this speaker features a low-profile design, making it ideal for blending seamlessly into any environment.
- High-Quality Components: The LF driver features a 165 mm (6.5 in) polymer-coated aluminum cone, while the HF driver boasts a 25 mm (1 in) pure-titanium dome with cloth suspension for precise audio reproduction.
- Optimized Crossover Network: The 3rd order (18 dB/oct) Low Pass to the woofer and High Pass to the tweeter ensures a smooth and seamless audio transition between drivers.
- Convenient Connectivity: The screw-down Euroblock-type connector allows for secure and hassle-free input connections.
Elevate Your Audio with JBL Control 126WT
Upgrade your audio experience with the JBL Control 126WT In-Wall Installation Speaker. Whether it's for background music in restaurants, paging in offices, or audio reinforcement in commercial spaces, this speaker delivers exceptional sound quality that captivates audiences. With its wide frequency range, flexible power options, and easy installation, the JBL Control 126WT is a versatile and reliable choice for any application requiring high-performance audio. Let this in-wall speaker elevate your sound system and immerse your audience in a world of pristine sound.
Specifications
| Specification | Value |
|---|---|
| Frequency Range | 38 Hz - 20 kHz (-10 dB) |
| Power Rating | 200 W Peak 100 W Continuous Program Power 50 W Continuous Pink Noise |
| Transformer Taps | 70 V: 30 W, 15 W, 7.5 W & 3.7 W taps |
| Sensitivity | 88 dB SPL |
| Coverage Angle | 180°H x 160°V |
| Impedance | 8 ohms |
| Drivers | LF: 165 mm (6.5 in) polymer-coated aluminum cone. HF: 25 mm (1 in) pure-titanium dome with cloth suspension on low-diffraction swivel-mount with -10 degree aimability. |
| Input Connectors | Screw-down Euroblock-type connector. Max wire size 14 AWG (1.5 mm)2 |
| Crossover Network | 3rd order (18 dB/oct) Low Pass to the woofer and 3rd order (18 dB/oct) High Pass to the tweeter. |
| Optimum Air Cavity Behind Speaker | 20 to 40 liters (0.7 to 1.4 cu ft) |
| Outside Dimensions (H x W x D) | 280 x 215 x 105 mm (11 x 8.5 x 4.1 in), 99 mm (3.8 in) front of wall to back of speaker. |
| Maximum Wall Thickness | 2 mm (1.25 in) |
| Cutout Size (H x W) | 246 x 181 mm (9.7 x 7.2 in) |
Elevate your audio system with the JBL Control 126WT In-Wall Installation Speaker. From its precise audio reproduction to its easy integration, this speaker ensures a captivating sound experience. Whether for background music or audio reinforcement, the JBL Control 126WT delivers outstanding performance in any setting. Upgrade your sound system with confidence and let this powerful in-wall speaker immerse your space in exceptional sound.
