Details
Highlights
- Wide Frequency Response: The FreeSpace 3 Series II Acoustimass module offers a frequency response of 50 Hz to 230 kHz (+/-3 dB) and 40 Hz to 315 Hz (-10 dB), providing deep bass and clear low-frequency reproduction.
- Omni-Directional Dispersion: With an omni-directional dispersion below 200 Hz, this module evenly distributes bass frequencies, filling the room with immersive and powerful sound.
- High Power Handling: The Acoustimass module can handle 200W long-term power (800W peak) in mono mode at 70/100 V, or 50W per channel (200W peak) in stereo mode and 100W (400W peak) in mono mode at low impedance, ensuring robust and dynamic audio performance.
- High Sensitivity: With a sensitivity of 76 dB SPL (Per channel) and 79 dB SPL (Mono) / 1W @ 1m, this module delivers impressive sound output even at lower power levels.
- Compact and Versatile Design: The FreeSpace 3 Series II Acoustimass module features a compact design, making it easy to integrate into various audio setups, from commercial installations to professional audio systems.
FreeSpace 3 Series II Acoustimass Module
Enhance your audio system with the FreeSpace 3 Series II Acoustimass module. This versatile and powerful bass module delivers deep and impactful low-frequency reproduction, elevating your listening experience with rich and immersive sound.
| Frequency Response (+/-3 dB): | 50 Hz - 230 kHz |
| Frequency Range (-10 dB): | 40 Hz - 315 Hz |
| Nominal Dispersion: | Omni-directional below 200 Hz |
| Long-Term Power Handling: | 70/100 V: 200 W (800 W peak) mono Low impedance: 50 W (200 W peak) per channel stereo or 100 W (400 W peak) mono |
| Sensitivity (SPL / 1 W @ 1 m): | Per channel: 76 dB SPL Mono: 79 dB SPL |
| Maximum SPL @ 1 m: | Per channel: 96 dB SPL (102 dB SPL peak) Mono: 102 dB SPL (108 dB SPL peak) |
| Nominal Impedance: | 6 Ω mono direct (transformer bypassed) |
Take your audio system to new depths with the FreeSpace 3 Series II Acoustimass module. With its wide frequency response, this module reproduces deep bass and low-frequency details, delivering an immersive audio experience for music, movies, and presentations.
The omni-directional dispersion below 200 Hz ensures that bass frequencies are evenly distributed throughout the listening area, filling the room with rich and powerful sound. Whether you're setting up a commercial sound system or a professional audio installation, this bass module brings life to your audio content.
